Iridium Coated Titanium Mesh 2.0 Micron

Name: Iridium Coated Titanium Mesh 2.0 Micron
Brand: Anping County Huihao Wire Mesh Manufacture Co., Ltd
SKU: Iridium Coated Titanium Mesh
Availability: InStock

Model Number:	Iridium Coated Titanium Mesh
MOQ:	1 square meter
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000 ROLLS PER 30 DAYS

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001-2015

Name:

Iridium Coated Titanium Mesh

Material:

Pure Titanium Grade1 Or Grade2

Anode Coat:

Iridium Oxide

Mesh Type:

Expanded Mesh

Coating Thickness:

2.0 Micron

Melting Point:

1668℃

Mesh Opening:

2x3mm

Shape:

To Be Your Drawing Request

Packaging Details:

Water-proof, plastic paper, wooden case, pallet

Supply Ability:

1000 ROLLS PER 30 DAYS

Highlight:

Iridium Coated Titanium Mesh

Grade2 Titanium Mesh

2.0 Micron Titanium expanded mesh

Product Description

Iridium Coated Titanium Mesh

Quick details of Iridium Coated Titanium Mesh

Anode Material: Pure titanium Grade 2;
Anode Coating: Iridium oxide;
Coating Thickness: 2.0 Micron;
Anode Shape: Diamond Mesh;
Dimension: As Per your drawing; common size is square, round and rectangle
Application: Electrochemical COD,ammonia nitrogen removal;

Description of Iridium Coated Titanium Mesh

Ruthenium-Iridium coated Titanium Anodes are a type of mixed-metal oxide (MMO) anode used in electroplating, water treatment, and other electronic applications. Ruthenium-Iridium coated Titanium Anodes are generally immediately available in most volumes and can be fabricated in forms such as sheet, mesh, perforated plate, rod, or wire.

Using state-of-the-art technology, the titanium base is taken to a high temperature ( ≥1200 °C) in a vacuum sintering furnace ensuring total adhesion of the coating. Thus, the coating consumption rate is extremely low and uniform, measured in milligrams per ampere-year.

Ruthenium-Iridium coated Titanium Anodes Properties (Theoretical)

Compound Formula	Ti
Molecular Weight	47.86
Appearance	Silver sheets or plates
Melting Point	1668 °C
Boiling Point	3560 °C
Density	4.54 g/cm3
Solubility in H2O	N/A

Specification of Titaium mesh- expanded mesh sheet

Overall Thickness	Design Size (in.)		Opening Size (in.)		Strand Size (in.)
	SWD	LWD	SWO	LWO	Width	Thickness
.050	.140	.280	.085	.185	.029	.024
.070	.165	.400	.115	.260	.035	.024
.060	.230	.500	.170	.370	.036	.024
.083	.220	.400	.140	.240	.035	.024
.085	.220	.400	.140	.240	.045	.030
.080	.270	.600	.200	.440	.045	.024
.088	.270	.600	.200	.440	.050	.030
.172	.630	1.575	.428	1.260	.110	.060
