products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Ultra Fine Wire
Created with Pixso.

Cut Resistant Stainless Steel Filament 0.025mm-0.08mm Wire Diameter

Cut Resistant Stainless Steel Filament 0.025mm-0.08mm Wire Diameter

Cut Resistant Stainless Steel Filament 0.025mm-0.08mm Wire Diameter

Model Number: HH-FINEWIRE
MOQ: one spool
Price: contact with us
Payment Terms: L/C, T/T, Western Union, Alipay
Supply Ability: 3000 spool PER 30 DAYS
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO9001-2015
Name:
Cut Resistant Stainless Steel Filament
Wire Diameter:
0.025mm-0.08mm
Material:
SS304L, SS316L
Electrical Conductivity S*m/mm²:
1.33 -1.37
Resistance %IACS:
2
Package Type:
Spool
Packaging Details:
10 spool PER carton
Supply Ability:
3000 spool PER 30 DAYS
Highlight:

Cut Resistant Stainless Steel Filament

,

stainless steel 316l filament 0.025mm

,

0.08mm 316 stainless steel filament

Product Description



Cut Resistant Stainless Steel Filament



Quick details of Cut Resistant Stainless Steel Filament



Small diameter:0.025-0.08mm
Material: AISI 304,304L,316,316L
Soft(annealed) and Bright
High precision control in size ±0.001mm
Multiple types of spool are available



Specification of Cut Resistant Stainless Steel Filament



Item Grade Size(mm) Size(micro) g/spool
Stainless Steel Filament – 0.025mm AISI 304/304L 0.025mm 25 microns 250-600
Stainless Steel Filament – 0.030mm  AISI 304/304L 0.030mm 30 microns 250-600
Stainless Steel Filament  – 0.035mm AISI 304/304L 0.035mm 35 microns 250-600
Stainless Steel Filament – 0.040mm AISI 304/304L 0.040mm 40 microns 250-600
Stainless Steel Filament – 0.045mm  AISI 304/304L 0.045mm 45 microns 250-600
Stainless Steel Filament – 0.050mm AISI 304/304L 0.050mm 50 microns 250-600
Stainless Steel Filament  – 0.060mm  AISI 304/304L 0.060mm 60 microns 250-600
Stainless Steel Filament  – 0.025mm  AISI 316/316L 0.025mm 25 microns 250-600
Stainless Steel Filament – 0.030mm AISI 316/316L 0.030mm 30 microns 250-600
Stainless Steel Filament – 0.035mm  AISI 316/316L 0.035mm 35 microns 250-600
Stainless Steel Filament – 0.040mm AISI 316/316L 0.040mm 40 microns 250-600
Stainless Steel Filament – 0.045mm  AISI 316/316L 0.045mm 45 microns 250-600
Stainless Steel Filament– 0.050mm  AISI 316/316L 0.050mm 50 microns 250-600
Stainless Steel Filament  – 0.060mm  AISI 316/316L 0.060mm 60 microns 250-600



Cut Resistant Stainless Steel Filament method process:



The production methods of stainless steel microwire include traditional drawing and cutting method, melting and drawing method, cluster drawing method, scraping method, cutting method, etc. At present, the smallest fiber diameter can reach 0.025mm and the longest length can reach tens or even hundreds of meters.



Grade 304L 316L
Tensile strength N/mm² 850-970 740-840
Electrical conductivity S*m/mm² 1.37 1.33
Resistance %IACS 2 2
Density kg/dm³ 7.9 7.9



Application of Cut Resistant Stainless Steel Filament



Textile products,Filters,Cleaning products,Aerospace,Chemical industry, Medical treatment,Electronic wires,etc.





Cut Resistant Stainless Steel Filament 0.025mm-0.08mm Wire Diameter 0



Spool type details




HK100(1)
HK100(2)
HK115
K90*100
PL-1
KK80
KK125
D1
100
100
115
90
80
80
125
D2
74
74
88
60
60
53
80
D3
25
59
25
20
20
20
26
L1
160
160
140
120
120
100
160
L2
85
90
80
100
100
70
90
Weight(g)
274
350
272
100
76
82
337



Cut Resistant Stainless Steel Filament 0.025mm-0.08mm Wire Diameter 1
