Home Products

Special Mesh

Titanium Special Mesh For Filter Elements

Name: Titanium Special Mesh For Filter Elements
Brand: Anping County Huihao Wire Mesh Manufacture Co., Ltd
SKU: HH-TIS
Availability: InStock

Model Number:	HH-TIS
MOQ:	1 square meter
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000 ROLLS PER 30 DAYS

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001-2015

Name:

Titanium Special Mesh

Usage:

Filter Elements

Material Grade:

TA1, TA2, GR1, GR2, R50250

Mesh:

9-150

Open Area:

21-91.7%

Mesh Cuatomized:

Cut Into Different Size And Shape

Sample:

Available For Stock Materials

Factory:

More Than 20 Years

Packaging Details:

Water-proof, plastic paper, wooden case, pallet

Supply Ability:

1000 ROLLS PER 30 DAYS

Highlight:

Titanium Special Mesh

Filter Special Mesh

TA1 Special Mesh

Product Description

Pure 99.99% Ti Wire Mesh Titanium Woven Wire Cloth For Seawater Filter Titanium Wire Mesh, Titanium Woven Wire Mesh, Titanium Filter Mesh Screen, Titanium Mesh

Quick details of Titanium Special Mesh

Material grade: TA1, TA2, GR1, GR2, R50250.
Weaving type: plain weave, twill weave and dutch weave.
Wire diameter: 0.002''-0.035''
Mesh size: 4mesh-150mesh.
Color: black or bright

Description of Titanium Special Mesh

Titanium woven special mesh is woven from non-magnetic titanium wires and is divided into black titanium woven mesh and white titanium woven mesh by its surface color. Black titanium woven mesh is made of pure titanium wire and is suitable for manufacturing ship and seawater titanium filter mesh; white titanium woven mesh is produced by weaving pure graphite wire after removing the graphite emulsion coating.

Specification of Titanium Special Mesh

Mesh(Wires/ in.	Wire diameter (in.)	Width of opening (in.)	Open area (%)
9 x 9	0.0320	0.0790	50.60
10 x 10	0.0350	0.0650	42.30
10 x 10	0.0300	0.0700	49.00
10 x 10	0.0250	0.0750	56.30
12 x 12	0.0110	0.0723	75.30
14 x 14	0.0160	0.0550	60.20
16 x 16	0.0060	0.0565	81.70
18 x 18	0.0100	0.0460	67.40
18 x 18	0.0110	0.0445	64.40
18 x 18	0.0160	0.0400	50.8
20 x 20	0.0030	0.0470	88.40
20 x 20	0.0200	0.0300	36.00
20 x 20 TW	0.0160	0.0340	46.20
24 X 24	0.0100	0.0320	57.90
24 X 24	0.0118	0.0290	51.40
26 X 26	0.0100	0.0233	54.90
30 X 30	0.0100	0.0210	49.00
32 X 32	0.0100	0.0206	46.50
35 X 35	0.0080	0.0200	51.80
40 X 40	0.0050	0.0150	64.00
40 X 40	0.0100	0.0110	36.00
50 X 50	0.0090	0.0110	30.30
50 X 50 TW	0.0040	0.0160	64.00
60 X 60 TW	0.0090	0.0077	21.30
90 X 90	0.0040	0.0071	41.00
100 X 100	0.0020	0.0080	64.00
120 X 120TW	0.0040	0.0043	27.00
150 X 150TW	0.0027	0.0040	35.50

Titanium Special Mesh applications

Production of electrodes, battery collectors, fine chemical industry filtration, shipbuilding, seawater desalination, petroleum medical filtration and other industries
Shipbuilding, medicine, military industry, satellite and aerospace, chemical industry, environmental industry, mechanical industry, electroplating industry, petroleum, battery industry, pharmaceutics, surgery.
