Sintered Bronze Filters for Sound Reduction & Exhaust Gas Throttle

Quick details of Sintered Bronze Filters

• Nominal chemical composition: Cu-89% Sn-11%
• Sintering density: 4.5-6.5 g/cm3
• Void ratio:25%-43%
• Filter level:1-250μm
• Temperature suitability: oxidizing atmosphere: -250℃ to200℃ reducing
• Atmosphere:-250℃ to 450℃
• Tensile strength: 9.8 to 83.4MPa

Description of Sintered Bronze Filters

Sintered bronze filter is a kind of filter made of spherical bronze powder particles selected and sintered, which is known as a sintered powder filter, sintered copper powder filter element, sintered bronze porous filter, muffler, silencer, copper powder filter.

sintered bronze filter is created using sintering, where fine bronze powder particles are heated and pressed together to form a solid but porous structure. This design allows the filter to allow fluids or gases to pass through while capturing unwanted particles.

Specification of Sintered Bronze Filters

Features of Sintered Bronze Filters

• High filtration accuracy. 5–50 μm
• Material saving. One-time molding, no cutting, and high utilization of raw materials
• High mechanical strength. Good rigidity, plasticity, oxidation resistance, and corrosion resistance
• Good air permeability. Suitable for fluid distribution, homogenization, and other occasions requiring high uniformity
• Simple and convenient installation and maintenance. Simple installation and use, easy maintenance, good assembly, can be welded, bonded, and machined.

Application of Sintered Bronze Filters

Sintered bronze filter is often used for medium purification and flow limitation of pneumatic components, lubricating oil, fuel oil, hydraulic pneumatic system, compressed air
