Special Shielding Performance Blackened Ultra Fine Copper Mesh Screen Cloth

Name: Special Shielding Performance Blackened Ultra Fine Copper Mesh Screen Cloth
Brand: Anping County Huihao Wire Mesh Manufacture Co., Ltd
SKU: HH-BCWM
Availability: InStock

Model Number:	HH-BCWM
MOQ:	1 roll
Payment Terms:	L/C,T/T,Western Union,MoneyGram
Supply Ability:	3000 rolls per 28 days

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001-2015

Name:

Blackened Copper Wire Mesh

Material:

Pure Fine Copper Wire

Finshed:

Black Material Sprayed On The Outside

Mesh:

50-200

Application:

Special Shielding Performance

Copper Wire Dia:

0.04-0.18mm

Packaging Details:

roll with paper tube + wooden case

Supply Ability:

3000 rolls per 28 days

Highlight:

Blackened ultra fine copper mesh screen

Blackened woven copper cloth

pure fine copper mesh cloth

Product Description

Special Shielding Performance Blackened Copper Wire Mesh

Description of Blackened Copper Wire Mesh

Blackened copper wire mesh provides special shielding performance. Due to a layer of black material sprayed on the outside, it reduces glare and improves visibility, providing better visual effects compared to other shielding meshes. It can be used for EMI shielded windows and monitors, etc. to prevent EMI radiation and EMI wave interference and to guarantee that the equipment runs normally.

Specification of Blackened Copper Wire Mesh

Item	Mesh/Inch	Diameter		Opening		Weight
Item	Mesh/Inch	mm	inch	mm	inch	kg/m²
BCWM-1*	50	0.18	0.007	0.33	0.013	0.87
BCWM-2	60	0.16	0.006	0.26	0.01	0.83
BCWM-3	60	0.19	0.007	0.23	0.009	1.17
BCWM-4	70	0.12	0.005	0.24	0.01	0.54
BCWM-5	80	0.12	0.005	0.2	0.008	0.62
BCWM-6	80	0.13	0.005	0.19	0.007	0.73
BCWM-7*	100	0.1	0.004	0.15	0.006	0.54
BCWM-8	100	0.11	0.004	0.14	0.006	0.65
BCWM-9	104	0.06	0.002	0.18	0.007	0.2
BCWM-10*	120	0.09	0.004	0.12	0.005	0.52
BCWM-11*	120	0.058	0.002	0.15	0.006	0.22
BCWM-12*	120	0.08	0.003	0.13	0.005	0.41
BCWM-13	140	0.07	0.003	0.11	0.004	0.37
BCWM-14	145	0.045	0.002	0.13	0.005	0.16
BCWM-15*	150	0.06	0.002	0.11	0.004	0.29
BCWM-16*	150	0.05	0.002	0.12	0.005	0.2
BCWM-17	160	0.05	0.002	0.11	0.004	0.22
BCWM-18	160	0.04	0.002	0.12	0.005	0.14
BCWM-19	160	0.035	0.001	0.12	0.005	0.11
BCWM-20	165	0.05	0.002	0.1	0.004	0.22
BCWM-21	180	0.05	0.002	0.09	0.004	0.24
BCWM-22	180	0.04	0.002	0.1	0.004	0.16
BCWM-23*	200	0.053	0.002	0.07	0.003	0.3
BCWM-24*	200	0.05	0.002	0.08	0.003	0.27
BCWM-25*	200	0.04	0.002	0.09	0.003	0.17

Features of Blackened Copper Wire Mesh

Good ductility and be made into various shapes
High conductivity and obtain good shielding effect
Be integrated into glass or plastic windows and provide better optical transparency than other meshes.
Stable black coating with uniform color and no pollution
