260 x 40 Reverse Dutch SS Wire Mesh

260*40 mesh Stainless Steel Reverse Dutch Wire Mesh Belt

Quick details of 260 x 40 Reverse Dutch SS Wire Mesh

Material: AISI302,304,316,316L,310S,410,430,904L,2205,2507,etc

Mesh count: 260 x40 mesh

Weave type: reverse Dutch weave

Wire Diameter: 0.150 × 0.220

Absolute Filtration Value: 80-95

Nominal Filtration Value: 125

Maximum Width: 1300mm

Description of Reverse Dutch SS Wire Mesh

Reverse dutch SS wire mesh is another product specially designed for filtering. It is mainly made of stainless steel wire, which is chemical resistance, alkali and acid resistance, rust and corrosion resistance. It can ensure the durable filtering performance during the usage. The reverse dutch weave can also be used in brass wire, which is also has chemical stability for filtering.

Using two different sizes of wire diameter, the stainless steel wire or brass wire is woven into reverse dutch woven ss wire mesh.

Reverse dutch ss wire mesh. The coarser wire in the weft direction and the finer wire in the warp direction.

Common Specification reverse dutch ss wire mesh

Standard specifications:

48 × 10 mesh RDPW 400 nominal micron.
72 × 15 mesh RDTW 250 nominal micron.
132 × 17 mesh RDTW 200 nominal micron.
152 × 30 mesh RDTW 115 nominal micron.
260 × 40 mesh RDTW 75 nominal micron.

Smooth surface, high hardness, continuous net, no deformation, high temperature resistance, corrosion resistance and outstanding filtering performance.

Package of ss wire mesh

• Waterproof brown paper for moisture resistance.
• Plastic paper for dust resistance.
• Wooden box or pallet for convenient to load and transport.
