165 250 325 500 Stainless Steel Screen Printing Mesh AISI304/ 316 Plain Weave Wire Mesh

Name: 165 250 325 500 Stainless Steel Screen Printing Mesh AISI304/ 316 Plain Weave Wire Mesh
Brand: Anping County Huihao Wire Mesh Manufacture Co., Ltd
SKU: HH-SSPRINT
Availability: InStock

Model Number:	HH-SSPRINT
MOQ:	1 m2
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	10000 square meters per 30 days

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001-2015

Name:

Stainless Steel Screen Ptinting Mesh

Material:

AISI304/ 316

Mesh Count:

165, 250,325,500

Application:

Solar Panel Printing

Weave Type:

Plain Weave.

Width:

48" Or 40" Or Other Customized Widths

Length:

30 M And Customized Lengths

Theoretical Ink:

15.3-42 Cm3/m2

Packaging Details:

inside use carton pipe for support+wire mesh layer+water proof paper

Supply Ability:

10000 square meters per 30 days

Highlight:

500 stainless steel screen printing mesh

AISI304 / 316 plain weave wire mesh

165 screen printing mesh

Product Description

165 250 325 500 Stainless Steel Screen Printing Mesh

165 250 325 500 mesh stainless steel 304 316 screen printing mesh

Quick Details of stainless steel screen printing mesh

Material: stainless steel 304 or 316

Mesh: 165, 250, 325, 500

Standard width: 1000mm, 1220mm

Standard roll length: 30 meters

Open Area: 25%-47%

Application:

Solar panel printing

PCB (Printed Circuit Boards) screen printing

Textile screen printing

Glass screen printing

Ceramic screen printing

Plastics & packaging

Membrane switches

Desprciption of stainless steel screen printing mesh

Stainless steel printing screen mesh is an ultra-thin and high transparency woven mesh, featuring uniform mesh openings and excellent durability. Made from high-quality stainless steel and other materials, combined with advanced weaving technology, it ensures a tight mesh structure that meets the stringent requirements of high-precision printing. Its applications are extensive, primarily used in circuit board printing, textile printing, ceramic printing, and glass printing, among other fields.

Standard specification of stainless steel screen printing mesh

SPECIFICATIONS OF STAINLESS STEEL PRINTING SCREEN MESH
Item	Mesh count	Thread Diameter	Open Area	Aperture	Theoretical ink
Item	mesh/inch	μm	%	μm	cm³/m²
SPMS-200-50	200	50	37.0	77	42.0
SPMS-230-35	230	35	46.7	75	37.0
SPMS-250-40	250	40	36.8	62	34.0
SPMS-250-30	250	30	49.7	72	30.0
SPMS-250-35	250	35	43.0	67	32.0
SPMS-270-35	270	35	39.4	59	30.0
SPMS-300-30	300	30	41.7	55	28.0
SPMS-325-30	325	30	38.0	48	24.0
SPMS-325-28	325	28	41.2	50	26.4
SPMS-325-23	325	23	49.8	55	25.4
SPMS-350-25	350	25	43.0	48	18.7
SPMS-400-23	400	23	40.7	41	19.0
SPMS-400-18	400	18	51.3	46	20.0
SPMS-500-18	500	18	41.7	33	15.3

Advantage of stainless steel screen printing mesh

High corrosive resistance.

Good heat-melting resistance.

Good solvent resistance.

High tension and low elongation.

Wide ranges of mesh counts for choice.

Special discount for large orders.

Large stocks for urgent orders.

ISO certificated factory
