304 316 Stainless Steel Wire Mesh Used In Various Filter Ss Wire Mesh

304 316 Stainless Steel Wire Mesh Used In Various Filter Ss Wire Mesh

Model Number:	HH-SSF0
MOQ:	1 square meter
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000 rolls per month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001-2015

Name:

Stainless Steel Wire Mesh

Material:

Stainless Steel Fine Wire

Weave Type:

Plain Weave,Twill Weave,Dutch Weave

Mesh Count:

2 - 635 Mesh, 12x64 - 500x3500 Mesh

Common Roll Width:

1m, 1.2m, 1.22m, 1.5m, 2m, 3m, 4m Etc

Common Roll Length:

30m, 40m, 50m, 60m Etc

Special Specification:

Can Be Customized

Factory Experience:

More Than 25 Years

Packaging Details:

1.waterproof paper inside,plastic film outside,then in wooden box. 2.waterproof paper inside,plastic film outside,then in wooden pallet.

Supply Ability:

1000 rolls per month

Highlight:

304 Stainless Steel Wire Mesh

316 Stainless Steel Wire Mesh

Plain weave ss wire mesh

Product Description

304 316 Stainless Steel Wire Mesh used in various filter

Quick details of stainless steel wire mesh

Stainless steel available: 304, 304L, 316, 316L, 310s, 904L, 430, etc

Weave Types: Plain Weave,Twill Weave,Dutch or 'Hollander' Weave,Plain Dutch Weave Twill Dutch Weave,Reverse Dutch Weave,Multiplex Weave.

Mesh width: Standard less than 2000 mm

Mesh type: Rolls and sheets are available

Production standard: ASTM E2016 - 20

Specification customization: Wire Diameter, Mesh Count, Weave type Woven wire mesh is available on the roll or cut to size Provide fine and strict packaging to ensure that the goods will not be damaged

Description of stainless steel wire mesh

Stainless steel wire mesh or woven wire cloth, is woven by machine. It is similar to the process of weaving clothing, but it is made of stainless steel fine wire. The stainless steel wire mesh can be woven in different weave styles. Its purpose is to produce solid and reliable products to adapt to various complex application environments.High precision technology makes the production cost of woven wire mesh higher, but it also has a very wide range of usages.

Specification of stainless steel wire mesh

Plain & Twill Weave Woven Wire Cloth Standard Grades & Specifications

Mesh/inch	Wire Diameter (mm)	Aperture (mm)	Mesh/inch	Wire Diameter (mm)	Aperture (mm)
2mesh	1.80	10.90	60mesh	0.15	0.273
3mesh	1.60	6.866	70mesh	0.14	0.223
4mesh	1.20	5.15	80mesh	0.12	0.198
5mesh	0.91	4.17	90mesh	0.11	0.172
6mesh	0.80	3.433	100mesh	0.10	0.154
8mesh	0.60	2.575	120mesh	0.08	0.132
10mesh	0.55	1.990	140mesh	0.07	0.111
12mesh	0.50	1.616	150mesh	0.065	0.104
14mesh	0.45	1.362	160mesh	0.065	0.094
16mesh	0.40	1.188	180mesh	0.053	0.088
18mesh	0.35	1.060	200mesh	0.053	0.074
20mesh	0.30	0.970	250mesh	0.04	0.061
26mesh	0.28	0.696	300mesh	0.035	0.049
30mesh	0.25	0.596	325mesh	0.03	0.048
40mesh	0.21	0.425	350mesh	0.03	0.042
50mesh	0.19	0.318	400mesh	0.025	0.0385

Plain Dutch Weave & Twill Dutch Weave Woven Wire Cloth Specifications

Weave	Mesh	Warp Wire (in)	Shute Wire (in)	abs μm Rating	Nom μm Rating	Wt per 100 sq/ft
PDW	8X20	0.0140	0.0126	330-350	280	49
PDW	12X64	0.0240	0.0165	270-290	200	84
PDW	14X88	0.0200	0.0130	220-240	150	75
PDW	16X80	0.0169	0.0134	225-235	140	79
PDW	24X110	0.0150	0.0100	115-125	80	55
PDW - TWIN WARP	24X128	0.0100	0.0040	110-120	75	34
PDW	30X150	0.0090	0.0070	110-112	63	33
PDW - TWIN WARP	30X150	0.0090	0.0070	95-113	60	33
PDW	40X200	0.0070	0.0055	70-75	55	27
PDW	50X250	0.0055	0.0045	58-63	40	22
PDW	80X400	0.0050	0.0030	40-45	35	17
TDW	30X250	0.0100	0.0080	110-120	53	66
TDW	80X700	0.0040	0.0030	35-40	25	25
TDW	120X400	0.0040	0.0025	50-55	40	15
TDW	165X800	0.0028	0.0020	25-28	15	14
TDW	200X600	0.0024	0.0018	30	20	10
TDW	165X1400	0.0028	0.0016	16-20	10	14
TDW	200X1400	0.0028	0.0016	12-14	5	15
TDW	325X2300	0.0014	0.0010	8-9	2	10
TDW	400X2800	0.0010	0.0008	6-7	1	8

Application of stainless steel wire mesh

Perfectly suited for a wide array of architectural and functional purposes, stainless steel wire mesh is used in various industries. The petroleum, chemical environmental protection, mining, aerospace, paper making, electronic, metallurgical, food and pharmaceutical industries all utilize woven wire mesh.
