Stainless Steel Material Rope Safety Netting For Balustrading Fencing

Stainless Steel Material Rope Safety Netting For Balustrading Fencing

Brand Name:	HUIHAO KASITE
Model Number:	HH-RS-50
MOQ:	10 square meters
Price:	usd14-usd28/m2
Payment Terms:	T/T
Supply Ability:	60000 square meters per 30 days

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001-2015

Name:

Rope Safety Netting

Material:

Stainless Steel 304/ 316/316l

Tolerances:

DIN ISO 2768-1 V

Fire Resistance:

Class A1

Cable Connection:

Adjustable Screw-on Cross Clamp, Eye Nut,

Frame System:

Tube With Stainless Steel Railing

Packaging Details:

pallet or your requests

Supply Ability:

60000 square meters per 30 days

Highlight:

stainless steel rope safety netting

wire rope mesh for balustrading

fencing rope net with warranty

Product Description

Stainless Steel Material Rope Safety Netting For Balustrading Fencing

Rope safety netting is custom-made for each individual application. There are no limits as far as length and width are concerned. The only restrictions concern handling when the netting is installed. Large expanses are possible because the mesh panels can be fixed together without a visible seam. Diagonal and irregular geometries can also be adapted.

Border Construction of Rope Safety Netting

Border construction with eyelets, standard installation
Sides, with open cable ends for adaptations on site
Closed mesh with loose ferrule + connection ferrule, special border construction
Diagonal border construction with eyelets, standard
Diagonal mesh with eyelets at vertical border

Specification of Rope Safety Netting

Item No.s	Cable Diameter	Mesh Opening Size (W×H)
HH-32120F	1/8 inch (3.2 mm)	4.75 x 8.23 inch (120 x 207.8 mm)
HH-32102F	1/8 inch (3.2 mm)	4 x 6.9 inch (102 x 176.7 mm)
HH-3290F	1/8 inch (3.2 mm)	3.55 x 6.15 inch (90 x 156 mm)
HH-3276F	1/8 inch (3.2 mm)	3 x 5.2 inch (76 x 131.6 mm)
HH-3251F	1/8 inch (3.2 mm)	2 x 3.46 inch (51 x 88.3 mm)
HH-24102F	3/32 inch (2.4 mm)	4 x 6.9 inch (102 x 176.7 mm)
HH-2490F	3/32 inch (2.4 mm)	3.55 x 6.15 inch (90 x 156 mm)
HH-2476F	3/32 inch (2.4 mm)	3 x 5.2 inch (76 x 131.6 mm)
HH-2460F	3/32 inch (2.4 mm)	2.4 x 4.16 inch (60 x 104 mm)
HH-2451F	3/32 inch (2.4 mm)	2 x 3.46 inch (51 x 88.3 mm)
HH-2076F	5/64 inch (2.0 mm)	3 x 5.2 inch (76 x 131.6 mm)
HH-2060F	5/64 inch (2.0 mm)	2.4 x 4.16 inch (60 x 104 mm)
HH-2051F	5/64 inch (2.0 mm)	2 x 3.46 inch (51 x 88.3 mm)
HH-2038F	5/64 inch (2.0 mm)	1-1/2 x 2.6 inch (38 x 65.8 mm)
HH-1676F	1/16 inch (1.6 mm)	1.2 x 2.08 inch (76 x 131.6 mm)
HH-1651F	1/16 inch (1.6 mm)	2 x 3.46 inch (51 x 88.3 mm)
HH-1638F	1/16 inch (1.6 mm)	1-1/2 x 2.6 inch (38 x 65.8 mm)
HH-1630F	1/16 inch (1.6 mm)	1.2 x 2.08 inch (30 x 52 mm)
HH-1625F	1/16 inch (1.6 mm)	1 x 1.73 inch (25.4 x 44 mm)
HH-1238F	3/64 inch (1.2 mm)	1-1/2 x 2.6 inch (38 x 65.8 mm)
HH-1230F	3/64 inch (1.2 mm)	1.2 x 2.08 inch (30 x 52 mm)
HH-1225F	3/64 inch (1.2 mm)	1 x 1.73 inch (25.4 x 44 mm)
HH-1220F	3/64 inch (1.2 mm)	4/5 x 1.39 inch (20 x 34.6 mm)

Rope Safety Netting Shape and Design

The diamond-shaped X-TEND mesh flexibly plays with its geometry. Other mesh opening angles than 60° standard are project-wise feasible, either to obtain spatial curves and to form three-dimensional structures, or to achieve a different visual effect with a narrower or wider mesh pattern. Note that a homogenous tension across the entire mesh surface can be more difficult to realise than the standard 60° angle, depending on the geometry.

Basically, the more the mesh is opened, the wider but shorter the net - and vice versa. We recommend a maximum opening angle of 70-75°.
