Flexible Stainless Steel Cable Mesh For Fall Protection System

Brand Name:	HUIHAO KASITE
Model Number:	HH-SCM-1.5
MOQ:	10 square meters
Price:	USD14-USD28/M2
Payment Terms:	T/T
Supply Ability:	60000 SQUARE METERS PER 30 DAYS

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001-2015

Name:

Stainless Steel Cable Mesh

Application:

Fall Protection

Max Length:

6000mm

Max Height:

2500mm

Customized:

Installation System And Install Parts

Finished:

Colored Treatment

Packaging Details:

PALLET OR ACCRODING TO YOUR REQUAEST

Supply Ability:

60000 SQUARE METERS PER 30 DAYS

Highlight:

flexible stainless steel cable mesh

fall protection wire rope mesh

stainless steel safety mesh system

Product Description

Flexible Stainless Steel Cable Mesh For Fall Protection System

The horizontal mesh diamond direction is suitable for small, individual panels. When wire rope netting mesh panels are joined continuously, Huihao offers a vertical mesh diamond direction that can be assembled on-site with proper tools. For larger mesh widths and safety-critical applications, vertical mesh diamond direction is recommended.

Key Dimensions & Specifications

Maximum length: 6000 mm
Maximum height: 2500 mm
Profile diameter: Ø 16.0 mm to Ø 48.3 mm
Maximum weight: 50 kg
Special geometries available
Custom frame details upon request

Stainless steel cable mesh maintains its structural integrity under self-weight and additional loads. The uniform tension distribution across the rope net surface ensures exceptional stability.

Our cable mesh supports three-dimensional tension loads, with shaping controlled by strategic placement of tensioning elements. The lightweight construction offers excellent economic efficiency while maintaining structural performance.

Specification of Stainless Steel Cable Mesh

Item No.	Cable Diameter	Mesh Opening Size (W×H)
HH-32120F	1/8 inch (3.2 mm)	4.75 x 8.23 inch (120 x 207.8 mm)
HH-32102F	1/8 inch (3.2 mm)	4 x 6.9 inch (102 x 176.7 mm)
HH-3290F	1/8 inch (3.2 mm)	3.55 x 6.15 inch (90 x 156 mm)
HH-3276F	1/8 inch (3.2 mm)	3 x 5.2 inch (76 x 131.6 mm)
HH-3251F	1/8 inch (3.2 mm)	2 x 3.46 inch (51 x 88.3 mm)
HH-24102F	3/32 inch (2.4 mm)	4 x 6.9 inch (102 x 176.7 mm)
HH-2490F	3/32 inch (2.4 mm)	3.55 x 6.15 inch (90 x 156 mm)
HH-2476F	3/32 inch (2.4 mm)	3 x 5.2 inch (76 x 131.6 mm)
HH-2460F	3/32 inch (2.4 mm)	2.4 x 4.16 inch (60 x 104 mm)
HH-2451F	3/32 inch (2.4 mm)	2 x 3.46 inch (51 x 88.3 mm)
HH-2076F	5/64 inch (2.0 mm)	3 x 5.2 inch (76 x 131.6 mm)
HH-2060F	5/64 inch (2.0 mm)	2.4 x 4.16 inch (60 x 104 mm)
HH-2051F	5/64 inch (2.0 mm)	2 x 3.46 inch (51 x 88.3 mm)
HH-2038F	5/64 inch (2.0 mm)	1-1/2 x 2.6 inch (38 x 65.8 mm)
HH-1676F	1/16 inch (1.6 mm)	1.2 x 2.08 inch (76 x 131.6 mm)
HH-1651F	1/16 inch (1.6 mm)	2 x 3.46 inch (51 x 88.3 mm)
HH-1638F	1/16 inch (1.6 mm)	1-1/2 x 2.6 inch (38 x 65.8 mm)
HH-1630F	1/16 inch (1.6 mm)	1.2 x 2.08 inch (30 x 52 mm)
HH-1625F	1/16 inch (1.6 mm)	1 x 1.73 inch (25.4 x 44 mm)
HH-1238F	3/64 inch (1.2 mm)	1-1/2 x 2.6 inch (38 x 65.8 mm)
HH-1230F	3/64 inch (1.2 mm)	1.2 x 2.08 inch (30 x 52 mm)
HH-1225F	3/64 inch (1.2 mm)	1 x 1.73 inch (25.4 x 44 mm)
HH-1220F	3/64 inch (1.2 mm)	4/5 x 1.39 inch (20 x 34.6 mm)

Applications of Stainless Steel Cable Mesh

Balustrading
Fall protection systems
Security fencing
Trellis for small plants
Architectural decoration
Space separation
Shopfitting solutions
Building cladding
Railing refurbishment
